So, what is the difference between the two systems? The main difference rests in what the system will do with the data.
A control system will use the values from the sensors to take action and correct the error between the set point and the value read in real-time. Let’s take as an example a room temperature sensor (thermostat).
The control system will use that value to determine the signal to transmit to the heating element or the cooling system to keep the room within predetermined parameters.
As for the monitoring system, it would still take the same data but would store it only at a predefined interval and send an alert without correcting anything if the minimum or maximum threshold was crossed.
Data can be stored for months or even years and can be used to prove that rooms were kept within the limits of acceptable parameters for the production process.
If that process is subject to the Code of Federal Regulations of the U.S. Food and Drug Administration (FDA), the monitoring system must comply with the 21 CFR Part 11 Guidance. This standard imposes some security requirements on electronic records so they cannot be falsified.
When both systems are required and use the same parameters, two sensors installed for each data point are frequently seen. One communicates with the control system, and the other communicates with the monitoring system.
It can be interesting to have some redundancy; however, that means having twice as many sensors to calibrate, and drift between the two readings is inevitable.
This difference is unwanted since the control system adjusts itself in real-time with one set of data that might differ from the other set of data read by the monitoring system.
The cleanroom operator could then note a value out of the limits set by his or her monitoring system while the control system would operate thinking it is still within limits.
So, what is the difference between the two systems? The main difference rests in what the system will do with the data.
A control system will use the values from the sensors to take action and correct the error between the set point and the value read in real-time. Let’s take as an example a room temperature sensor (thermostat).
The control system will use that value to determine the signal to transmit to the heating element or the cooling system to keep the room within predetermined parameters.
As for the monitoring system, it would still take the same data but would store it only at a predefined interval and send an alert without correcting anything if the minimum or maximum threshold was crossed.
Data can be stored for months or even years and can be used to prove that rooms were kept within the limits of acceptable parameters for the production process.
If that process is subject to the Code of Federal Regulations of the U.S. Food and Drug Administration (FDA), the monitoring system must comply with the 21 CFR Part 11 Guidance. This standard imposes some security requirements on electronic records so they cannot be falsified.
When both systems are required and use the same parameters, two sensors installed for each data point are frequently seen. One communicates with the control system, and the other communicates with the monitoring system.
It can be interesting to have some redundancy; however, that means having twice as many sensors to calibrate, and drift between the two readings is inevitable.
This difference is unwanted since the control system adjusts itself in real-time with one set of data that might differ from the other set of data read by the monitoring system.
The cleanroom operator could then note a value out of the limits set by his or her monitoring system while the control system would operate thinking it is still within limits.
